Description:
The EN insulator is a full hexagonal insulator, designed to securely support and fix busbars at any clamping height. It is a specialized component developed to meet the usage requirements, installation methods, and environmental conditions of equipment used in communication cabinets, electrical systems, lightning protection devices, mechanical systems, medical equipment, wind power systems, and variable frequency devices. Its primary functions include supporting, connecting, and insulating electrical components.
Certifications:
CE, SGS, RoHS certified
Technical Specifications:
- Model: EN
- Thread Sizes: M6 / M10 / M12
- Material: DMC, BMC
- Voltage Rating: 660V – 4500V
- Flame Rating: UL94-V0
- Customization: Non-standard specifications available upon request
- Application: Support and connection for busbars
| Model | Diameter D (mm) | Height H (mm) | Thread (S) | Customization |
|---|---|---|---|---|
| EN25 | 26 | 25 | M6 / M8 | – |
| EN30 | 26 | 30 | M6 / M8 | – |
| EN32 | 26 | 32 | M6 / M8 | – |
| EN40 | 26 | 40 | M6 / M8 | – |
| EN50 | 26 | 50 | M6 / M8 | – |
| EN60 | 26 | 60 | M6 / M8 | – |
| EN80 | 45 | 80 | M10 / M12 | – |
| EN90 | 45 | 90 | M10 / M12 | – |
| EN100 | 45 | 100 | M10 / M12 | – |
| EN110 | 45 | 110 | M10 / M12 | – |
| EN120 | 45 | 120 | M10 / M12 | Customizable upon request |
